The CORE 500™ is the modern stethoscope replacement, combining 3-lead ECG, unmatched audio clarity, and waveform visualizations, with available Eko+ connectivity for AI insights, exam recording, and sharing. Experience 8x sound improvement¹ and detect heart disease at double the rate² compared to a traditional stethoscope.
The CORE 500™ improves diagnostic confidence with unmatched audio quality and 3-lead ECG data. As an Eko+ member, you can easily record, share, and analyze body sounds for faster, more accurate care.
- Hear with precision, even in noisy environments: TrueSound™ technology unlocks active noise cancellation and up to 40x sound amplification, allowing you to hear body sounds more clearly for confident diagnoses.
- See insights in seconds: The full-color display shows 1-lead ECG, exam details, and device settings directly on the stethoscope, streamlining your workflow and providing essential data right at your fingertips.
- Expand your cardiac assessments: The integrated 3-lead ECG offers a more comprehensive view of your patient’s heart, improving diagnostic accuracy.
- Detect disease earlier: Unlock murmur and AFib detection powered by Eko AI, along with sound recording, sharing, and more, with an Eko+ membership for earlier diagnoses and seamless collaboration.
- Designed to last: The CORE 500™ is scratch and splash proof, with a battery life of up to 60 hours, ensuring it stays powered through even the longest shifts. The 1-year warranty and 30-day risk-free trial will give you peace of mind, too.
- TrueSound™ technology with in-ear speakers
-
- Full-color LCD display
- 3-lead ECG with frequency response range from 0.1-250 Hz
- Up to 40x amplification
- Active noise cancellation
- Bluetooth wireless listening option
Power
- Auto power off
- USB-C charging port
- Rechargeable lithium-ion battery that lasts up to 300 minutes of continuous use; generally lasts up to 60 hours of regular clinical use
Connection & Storage
- Bluetooth 4.2 low-energy
- Patient report in .PDF file format
Dimensions & Weight
- 27 in (69 cm) L from ear tip to chestpiece
- 6.6 oz (186 gm)
- Chestpiece weight: 3.1 oz (88 gm)
- Diaphragm diameter: 1.2 in (3.0 cm)
Construction & Materials
- Binaural: TRS jack connector, vinyl tube, and sealed speaker
- Chestpiece technology: Single-sided with 3 equally spaced, custom-sized electrodes
- Diaphragm material: Silicone
- Diaphragm shape: Round
- Diaphragm type: Tunable, single-piece
- Headset material: Anodized aluminum
- Ear tips material: Silicon
- IP44 water rating
- Does not contain natural rubber latex or phthalate plasticizers
What’s Included
-
Certifications & Licenses
- FDA Cleared
- UKCA Marking
- ISO 13485 Certified
- MDSAP Certified
- HIPAA Compliant
- GDPR Compliant
